Customized portable handheld 10-band wireless microphone (VHF and UHF

• Antenna: 10 omnidirectional antennas
• Shielding radius: 0-15m (the interference radius still depends on the signal strength of the given area)
• Single output power: +30dBm /1W
• Power supply (charger): AC charger (input: AC100-240V) & car charger (DC12V car cigarette lighter)
• Battery type: Built-in 7.4V 4500mAh lithium-ion battery, fully charged, can work continuously for about 1.5 hours.
• Colour: Black
• Dimensions: 170×100×50 mm, without antenna (within 300mm antenna height)
• Weight: 800g
• Package weight: 1.4KG
• Working temperature: -40 to +55°C
• Relative humidity: ≤90% (RH)
• Air pressure: 86~106kPa

Package Content:

1. take out the device

2. screw the antenna to the right position according to the main unit indicated and put on the DIP switch (otherwise the jammer can not work)

3. switch on the electricity, the red light on, the jammer is working.

4. when the jamming range coming to dwindle, it shows the battery is going to out of work, should be charged.

(When charging, the charging indicators on the AC charger and the device will light red; After fully charged, the charging indicators will turn green).

5. since the valid scope covered by the jammer is a round area with the jammer as the center, put the jammer in the center place if possible to achieve a better shielding effect.

6. please keep away strong electromagnetic sources with heat sources to ensure good shielding effect and stable operation for a long time.

7. please don’t use it for a long time by continuous charging, otherwise the battery life will be shorten.

8. after use, please switch off the device in time to avoid affecting the normal use of the phone.

9. while using it outdoors, be sure to keep it away from water or damp.

10. keep away from caustic gases and liquids, and be sure to make it dust-proof and moisture-proof, lest the aging of the components inside should be accelerated.
